- Smalltalk code analysis/output framework -
(2021/11/11)
Dandelion is now on GitHub! I put the latest version (v0.6.1) for Squeak 5.3. You can also install Dandelion directly from the SqueakMap Package Loader.
(2004/11/26)
Dandelion0.5beta3 for Squeak 3.7. XMI 1.2 support. Improved HTML source layout. Handling
DeclarativePools correctly. And some minor bug fixes. Enjoy!
(2003/5/22)
Dandelion0.5beta2. I've just added the slash patch.
(2003/5/20)
A small HTML outputter patch for / (slash) included category names. Not so common. But Seaside uses the character. See the example.
(2002/12/21)
Dandelion0.5beta1 is now available as Dandelion.sar for SqueakMap. Install instantly and enjoy the power of the Dandelion!
(2002/04/13)
Dandelion0.5beta1. Partial XMI support. You can now generate XMI UML files by Dandelion. Analyze your project
and see it with the various case tools which support XMI (MagicDraw UML,
Argo UML, etc)! Here is the MagicDraw sample screenshot.
(2002/02/27)
Patch for Squeak3.2gammma. Added an minor exception handling code.
(2001/11/21)
Dandelion 0.4final4. Minor bug fixes for Petal output. Added a new example.
(2001/05/24)
I put Dandelion 0.4final3. It has a minor code polishing on PetalElement (for portability). Dandelion0.4
now could run even in Squeak2.7. Thanks Mr. Mark Taylor for suggesting
that.
(2001/04/13)
Dandelion 0.4final could not be loaded in Squeak3.0 image. Actually, it
had a very minor bug in pal outputter . (The bug was about block variable
- Squeak formatter seemed to insert an evil code).
The bug was fixed. Please use Dandelion 0.4final2.
Thanks Mr. Yutaka Kamite for reporting that.
(2001/01/7)
At last, Dandelion 0.4 rolled out!
This version supports Rose Petal file output.
(2000/12/3)
Dandelion project is stopped and going away? - NO!
Actually, a pretty good Rose Petal outputter is emerging. Current snapshot is here. You will see the formal Dandelion 0.4 release at the beginning of the
next year!
(2000/07/23)
Dandelion 0.4 SP2 is available! It runs on Squeak2.8 and supports SMIX
output.
(2000/06/25)
SMIX outputter early access - see SMIX page. It can be used independently without loading whole Dandelion classes!
(2000/03/27)
Dandelion 0.4 sneak preview is now released!
Although it is not complete version, you will know where the Dandelion
is directed to.
(2000/02/10)
New sample output is available at Dandelion Samples (ignore banners...) This is based on Dandelion 0.4 pre-alpha version.
(2000/01/23)
BadNews: I noticed that patch2 had a wrong expression; "Smalltalk removeClassNamed:
#DlPortableFilePath". Now fixed... Sorry.
GoodNews: I confirmed that Dandelion 0.3 will run on Mac Squeak 2.7. Some people
reported me Dandelion did not run on Mac Squeak 2.4. The problem seemed
to be in VM.. Anyway, It is fixed.
And also, I announce that Dandelion 0.4 is just around the corner. Please
stay tuned.
(1999/07/03)
I put explanatory format SMIX for Smalltalk code interchange. . This is a tiny step toward the XMI support.
(1999/07/01)
I decided not to implement Rose model file outputter any more. Many case
vendors' move toward XMI is very, very rapid. So, I will implement a XMI (based on UML DTD) outputter. I think the translation from XMI to other proprietary format such as
Rose model file is easy by using some XSLT utilities.
Dandelion is a generic Smalltalk code analysis/output framework. You can analyze your code and output the information in various formats (currently HTML, SMIX, Petal, XMI).
Dandelion looks like a "doclet" in Smalltalk. And the impression is 80% right. However, I believe Dandelion has more flexibility. You can customize not only outputting format, but also analysis policy(what/how code elements will be analyzed) and analyzed information storage(how the analysis information is stored).
The first motivation that made me develop this system was " to make a grass-root Rose/Smalltalk". Actually I once developed Rose/Smalltalk Japanese version in 1996. The tool supported round trip developing process. Developers model application systems in Rose(at that time UML was before its birth, so mainly in Booch Method) and generate Smalltalk st-files(for VisualWorks) - This is called "forward engineering". Then you file-in skeleton st-files and substantiate and change them. The changed code information could be merged into the original model by using Smalltalk code analysis tool - This is called "reverse engineering". Round trip development would be possible only by using both forward engineering and reverse engineering. As you know, round trip process is very productive, because you can develop your system incrementally. Model a little, implement a little, and test a little - that leads to more bug-free reusable systems. Developers can easily repeat this cycle in every development phase, because the main interest is always "objects". This round trip process makes the best use of the main feature of OOA/OOD/OOP - the modeling traceability.
As an OO developer, now I always use Unified Modeling Language in real-world projects. I believe a lot of Smalltalkers would like to use a state-of-the-art round trip engineering tool which supports UML. Unfortunately, Rose/Smalltalk became obscure and UML version of Rose/Smalltalk is not released from Rational Software.VisualWorks/RoseLink from Cincom is only for VisualWorks and the price of the product is not reasonable for some developers. (The same could be said about IBM VisualAge Smalltalk UML Designer).
So I decided to make a new, free, highly-custmizable, round-trip engineering tool for Smalltalkers. The system would be called "Dandelion Round-tripper".
However,this is merely a personal project. I am too busy to develop a whole system. "Dandelion Round-tripper" is to be made of two parts - forward engineering part and reverse engineering part. As a first trial, I developed reverse engineering base module - which is now called "Dandelion"
"Dandelion" has no intended relation to Xerox old Smalltalk "D-machines" (Dorade, Dolphin,Dandelion,Daylight). It is only a coincidence, though I think those names are quite cool.
Squeak 2.8-3.7. (Sorry for VisualWorkers and other Smalltalkers. I'm now hooked on to Squeak. However, you can port Dandelion very easily. It is carefully implemented so as not to lose portability).
From Dandelion 0.5, at least Squeak 3.2 is required. (If you would like to run Dandelion 0.5 in Squeak 2.8-3.1, you should disable Patch for Squeak3.2gammma).
Dandelion 0.3 is under the GNU GPL version 2(or any later version).
or
The architecture of Dandelion is like a "Pipeline" [Pipes and Filters].
You can change/customize each part independently.
All those collaborations are constructed by lazy initializations. So you can set customized AnalysisStrategy or Outputter dynamically.(DlDandelionSystem provide easy-to-use interfaces).[Facade]
Anyway many thanks for the most innovative environment in the planet! Very productive and lots of fun! I love Squeak!
Any feedback is appreciated.
Masashi Umezawaalso see the SmallInterfaces Squeak
